Objectives

The objectives of this tutorial are:

1. Introduce the concept of a data frame
2. Demonstrate how data frames can be manipulated
3. Demonstrate how to reformat data and code for missing data
4. Explain data subsetting in R
5. Save imported data to a compact binary file

Introduction

This tutorial will show you how to view, subset and manipulate data frames within R. This assumes that the data have been successfully imported into R (if you are unsuccessful at importing data into R then you need to read the data importing worksheet).

The data we’ll be using have been imported from these files:

• WOLF.CSV: This file is a text file of comma separated variables.
• INSECT.TXT:This file is a text file of TAB delimited variables.

These data sets are described athttp://www.ucd.ie/ecomodel/Resources/datasets_WebVersion.html

Viewing a data frame

ls()                    # Display the variables in R's memory

[1] "insect" "wolf"

insect                    # Display the entire insect data frame

   Spray.A Spray.B Spray.C Spray.D Spray.E Spray.F  X X.1
1       10      11       0       3       3      11 NA  NA
2        7      17       1       5       5       9 NA  NA
3       20      21       7      12       3      15 NA  NA
4       14      11       2       6       5      22 NA  NA
5       14      16       3       4       3      15 NA  NA
6       12      14       1       3       6      16 NA  NA
7       10      17       2       5       1      13 NA  NA
8       23      17       1       5       1      10 NA  NA
9       17      19       3       5       3      26 NA  NA
10      20      21       0       5       2      26 NA  NA
11      14       7       1       2       6      24 NA  NA
12      13      13       4       4       4      13 NA  NA

head(wolf)              # Display the first 6 lines of the wolf data frame
tail(wolf, n=10)        # Display the last 10 lines of the wolf data frame
summary(wolf)           # Display an overview of the wolf data frame
str(wolf)               # Display the structure of the wolf data frame

wolf$Cpgmg     # Display just the cortisol data

# Variable names appear above each column of data
head(wolf)     # Display first 6 rows of data.

  Individual Sex Population Colour Cpgmg Tpgmg    Ppgmg
1          1   M          2      W 15.86  5.32       NA
2          2   F          1      D 20.02  3.71 14.37622
3          3   F          2      W  9.95  5.30 21.65902
4          4   F          1      D 25.22  3.71 13.42507
5          5   M          2      D 21.13  5.34       NA
6          6   M          2      W 12.48  4.60       NA

Adding a variable into a data frame

We can add a variable to a data frame using the$operator.
Here is an example where we add the variableReplicate(1-12) which codes for each replicate of an experimental treatment

insect$Replicate = c(1:12)   # Add a variable called Replicate to the data frame

head(insect)                 # Display the first 6 rows of the trimmed data frame

  Spray.A Spray.B Spray.C Spray.D Spray.E Spray.F  X X.1 Replicate
1      10      11       0       3       3      11 NA  NA         1
2       7      17       1       5       5       9 NA  NA         2
3      20      21       7      12       3      15 NA  NA         3
4      14      11       2       6       5      22 NA  NA         4
5      14      16       3       4       3      15 NA  NA         5
6      12      14       1       3       6      16 NA  NA         6

Changing a variable’s data type

Data in statistical analyses are often one of two basicdata types:quantitativeorqualitativedata.

• R calls a continuous quantitative variablenumeric(abbreviated tonum)
• R calls a discrete quantitative variableinteger(abbreviated toint)
• R calls a qualitative variable afactor

A qualitative variable is a set of labels (e.g. large, medium and small). Each label is called alevelof the factor.

R also has other data types. Some examples are:

• characterdata type = plain text (abbreviated tochr)
• logicaldata type = a variable that isTRUEorFALSE(abbreviated tologi)

In the wolf data frame the variablesPopulation,Individual,SexandColourare qualitative (the labels from each of these variables identify a data point to a population, an individual, a sex and a coat colour, respectively).

The data types that R has assigned each variable can be seen by looking at the structure of the wolf data frame

str(wolf)                    # Display the structure of the data frame

'data.frame':   178 obs. of  7 variables:
 $ Individual: int  1 2 3 4 5 6 7 8 9 10 ...
 $ Sex       : chr  "M" "F" "F" "F" ...
 $ Population: int  2 1 2 1 2 2 1 1 1 2 ...
 $ Colour    : chr  "W" "D" "W" "D" ...
 $ Cpgmg     : num  15.86 20.02 9.95 25.22 21.13 ...
 $ Tpgmg     : num  5.32 3.71 5.3 3.71 5.34 4.6 4.58 9.27 4.81 5.07 ...
 $ Ppgmg     : num  NA 14.4 21.7 13.4 NA ...

You can see some issues here:

• The variablesPopulationandIndividualhave not been assigned as quantitative variables (R has identified them as numericalintegers,int, because the wolf.csv file used whole numbers as labels for these two variables).
• The variablesSexandColourhave been identified as containing text (chrtype), but we want these to be recognised as qualitative nominal data types (R calls this data type afactor). The variableSexhas two levels ‘M’ and ‘F’. The variableColouralso has two levels ‘D’, ‘W’, and blank should be explicitly recognised as missing data.

We want to redefine the variablesPopulation,SexandColourso that R recognizes it as a factor (unorded factor). We will also redefine the variableIndividualto be plain text (i.e. a character) to demonstrate theas.character()function.

# Convert Population variable from numeric to a factor (a qualitative variable)
wolf$Population = as.factor(wolf$Population)

# Convert Sex variable from character to a factor (a qualitative variable)
wolf$Sex = as.factor(wolf$Sex)

# Convert Colour variable from character to a factor (a qualitative variable)
wolf$Colour = as.factor(wolf$Colour)

# Convert Individual variable from numeric to plain text
wolf$Individual = as.character(wolf$Individual)

# Display an overview of the data frame
summary(wolf)

  Individual        Sex    Population Colour      Cpgmg           Tpgmg
 Length:178         F:72   1: 45       : 30   Min.   : 4.75   Min.   : 3.140
 Class :character   M:76   2:103      D: 37   1st Qu.:12.16   1st Qu.: 4.372
 Mode  :character   U:30   3: 30      W:111   Median :15.61   Median : 5.070
                                              Mean   :17.74   Mean   : 6.148
                                              3rd Qu.:20.35   3rd Qu.: 6.317
                                              Max.   :73.19   Max.   :61.790

     Ppgmg
 Min.   :12.76
 1st Qu.:19.50
 Median :25.00
 Mean   :25.89
 3rd Qu.:30.01
 Max.   :53.28
 NA's   :109

Notice how the summary of the variablesPopulation,Sex,IndividualandIndividualhave changed now that they are factors. Also note that missing values,NA’s, are explicitly taken into account when summarizing the data (e.g. the variablePpgmg).

There are a set of related functions for coercing variables into other data types. Here are some examples

as.factor(...)    # Coerces a variable to be a factor (qualitative, nominal)
as.numeric(...)   # Coerces a variable to be numeric (quantitative, continuous)
as.character(...) # Coerces a variable to be a character (qualitative, unordered)

Removing a variable from a data frame

Sometimes we want to remove a variable from a data frame.

Theinsectdata frame has two variables that should not be part of the data set (XandX.1). This is quite common when importing data. In this case the reason is two additional TABs at the end of each line in the text file. These TABs are hard to see, but R recognized them, created two additional variables and named them with default labels.

The columns can be removed by first finding out how many rows and columns the data frame has and then removing the last two columns. Here is the code

ncol(insect)                # Number of columns in data frame
nrow(insect)                # Number of rows in data frame
dim(insect)                 # Display number of rows and columns

insect = insect[ ,-c(7,8)]  # Remove the last two columns

Set missing data to NA

Always useNAto represent missing data

Data on coat colour is missing for population 3. R explicitly represents missing data asNA, but the WOLF.CSV data file uses a blank space to represent missing data.

The code below sets these blank spaces toNA

# Create a logical variable that is TRUE if an observation is from population 3
bool.index = wolf$Population==3

# Set coat colour variable to be NA for observations from population 3
wolf$Colour[bool.index] = NA

Subset of a data frame

wolf.F = subset(wolf, Sex=='F') # Create a subset with data on female wolves

# Create a logical variable which is TRUE if an observation is for a female
bool.index = wolf$Sex=='F'

# Create a subset containing only data on female wolves
wolf.F2 = wolf[bool.index, ]

# Create a subset containing only data on female wolves in Population 1
# method 1:
wolf.F3 = subset(wolf, Sex=='F' & Population==1)

# Create a subset containing only data on female wolves in Population 1
# method 2:
bool.index = wolf$Sex=='F' & wolf$Population==1
wolf.F4 = wolf[bool.index,]

# Create a subset containing only data on wolves in Population 1 OR Population 2
wolf.F5 = subset(wolf, Population==1 | Population==2)

summary(wolf.F5)

  Individual        Sex    Population Colour      Cpgmg           Tpgmg
 Length:148         F:72   1: 45       :  0   Min.   : 4.75   Min.   : 3.250
 Class :character   M:76   2:103      D: 37   1st Qu.:12.16   1st Qu.: 4.378
 Mode  :character   U: 0   3:  0      W:111   Median :15.38   Median : 5.030
                                              Mean   :16.61   Mean   : 5.617
                                              3rd Qu.:19.98   3rd Qu.: 6.067
                                              Max.   :40.43   Max.   :15.130

     Ppgmg
 Min.   :12.76
 1st Qu.:19.50
 Median :25.00
 Mean   :25.89
 3rd Qu.:30.01
 Max.   :53.28
 NA's   :79

wolf.F5 = droplevels(wolf.F5) # Update the levels of factors in wolf.F5
summary(wolf.F5)              # The factor Population now has 2 levels

  Individual        Sex    Population Colour      Cpgmg           Tpgmg
 Length:148         F:72   1: 45      D: 37   Min.   : 4.75   Min.   : 3.250
 Class :character   M:76   2:103      W:111   1st Qu.:12.16   1st Qu.: 4.378
 Mode  :character                             Median :15.38   Median : 5.030
                                              Mean   :16.61   Mean   : 5.617
                                              3rd Qu.:19.98   3rd Qu.: 6.067
                                              Max.   :40.43   Max.   :15.130

     Ppgmg
 Min.   :12.76
 1st Qu.:19.50
 Median :25.00
 Mean   :25.89
 3rd Qu.:30.01
 Max.   :53.28
 NA's   :79

# Create a subset of the data containing the variables 'Population' and 'Cpgmg'
wolf.subset1 = subset(wolf, select=c('Population','Cpgmg'))

# Create a subset of the data containing the variables 'Population' and 'Cpgmg'
wolf.subset2 = wolf[,c('Population','Cpgmg')]


# Create a subset of the data containing the variables 'Population' and 'Cpgmg'
# (columns 3 and 5 in the wolf data frame)
wolf.subset3 = wolf[,c(3,5)]


# Create a subset of the data containing the variable 'Population'
# using the variable name
wolf$Population

# Create a subset of the data containing only female wolves and the
# variables 'Population' and 'Cpgmg'
wolf.subset4 = subset(wolf, Sex=='F', select=c('Population','Cpgmg'))

Saving data

Large data sets can be time consuming to import into R. Once a file has been imported it is a good idea to save the data in R’s native binary format. Data in this format is quick to import and takes up less space on the hard drive. By convention, files containing data in R’s binary format have the suffix.Rdata.

To save the variableswolf,insect.tidyandbeesto a file use thesave()command

# Save wolf, insect.tidy and bees to a file called 'sheet2_data.Rdata'
save(wolf, insect, file='sheet2_data.Rdata')

We can verify that the data have been correctly saved by clearing R’s memory and re-importing them using theload()command. Try running the following commands to see if you can reload the data saved in filesheet2_data.Rdata.

rm(list=ls())                           # Clear variables from memory
ls()                                    # Display the variables in R's memory
load(file='sheet2_data.Rdata')          # Import R binary data from a file
ls()                                    # Display the variables in R's memory

Summary of the topics covered

• Displaying contents of a data frame
• Manipulating data in a data frame
• Creating subset of data
• Saving a data frame to a file using R’s binary data file format
• Reading data from an R binary data file

Further Reading

All these books can be found in UCD’s library

• Andrew P. Beckerman and Owen L. Petchey, 2012Getting Started with R: An introduction for biologists(Oxford University Press, Oxford) [Chapter 3]
• Michael J. Crawley, 2015Statistics : an introduction using R(John Wiley & Sons, Chichester) [Chapter 2]
• Tenko Raykov and George A Marcoulides, 2013Basic statistics: an introduction with R(Rowman and Littlefield, Plymouth)
